GraphQL/Slices/Group Field/Link _Document meta

Developing with Prismic
1

Hi,

I have slices and in one of them I placed Group in the Repeatable zone and Link field inside the Group.
When I use Link field as a Content Relation and query it like this:

    body {
      ... on MySlice {

        fields {
          link_field {

            _linkType
            __typename

            ... on _Document {
              _meta {
                type
                uid
              }
            }

            ... on _ExternalLink {
              url
            }
          }
        }
      }
    }

In the WebGraphQL I get _meta field of the _Document, which proves that the Prismic api is working correctly, but when I call api, with the same query, from the server I don't get _meta.
ExternalLink works fine.

I am using Apollo Client.
Please let me know if you need any additional information.

Thank you.

2

So this is what I ended up doing. I am not sure if this is a workaround or the way it should be.
I used to pass empty array [] to the type property of the IntrospectionFragmentMatcher, but now I’m passing actual schema.

  1. I queried schema like this in the Prismic WebGraphql:
query {
  __schema {
    queryType {
      name
    }
    types {
      kind
      name
      possibleTypes {
        name
        fields {
          name
          type {
            kind
            fields {
              name
              type {
                kind
              }
            }
          }
        }
      }
      interfaces {
        name
      }
      fields {
        name
        type {
          kind
          name
        }
      }
    }
  }
}

Maybe this is too much data, but I haven’t had time to play around with it, it just works.

  1. When I got the result “data” field was the root property, that’s not going to work so I made __schema to be the root property, like this:
{
  "__schema": {
    "queryType": {
      "name": "Query"
    },
    "types": [
      // All types
    ]
  }
}

Save this to some .json file, link schema.json.

  1. I imported this file where I initialize IntrospectionFragmentMatcher add used .json schema file like this:
import {
  InMemoryCache,
  IntrospectionFragmentMatcher
} from "apollo-cache-inmemory";

const introspectionSchema = require('./schema.json')

const fragmentMatcher = new IntrospectionFragmentMatcher({
  introspectionQueryResultData: introspectionSchema
});

export default function createClient() {
  return new ApolloClient({
    link: ApolloLink, // This part you probably already have.
    cache: new InMemoryCache({ fragmentMatcher })
  });
}

That’s basically it.
I got the schema, saved it into .json file, passed this .json file to IntrospectionFragmentMatcher.
Hardcoding this might not be a good idea, but how you get the schema is up to you.

Here is a useful link:

P.S. Can somebody suggest an alternative, easier way of doing this?

6

Hi Nikola,

Welcome to Prismic community and that you for contributing.

Passing a json with the fragments type is the way to go, and here is similar implementation we have done:

Fares

7

This issue has been closed due to inactivity.
